Aluminum machining center

Box body and wide triangular baseFully enclosed protective coverDirectly connected high-speed high-precision spindleSuitable for processing various types of aluminum plates and new energy vehicle battery boxes

Inquiry

Key Features

Technical Specifications

Case Study

We believe the projects that we have executed speak for themselves. CITIC HIC has engineered and provided 6 AG mills of Ø12.2m×11m (28000kW gearless drive) and 6 overflow discharge ball mills of Ø7.9×13.6m (2×9000kW gear drive) for Sino Iron Project in Australia. For Zijin Mining’s Duobaoshan Copper Mine project in Heilongjiang, we have manufactured and provided SAG mills of Ø11×6.4m (2×9000kW) and overflow discharge ball mills of Ø7.9×13.6m (2×9000kW) which have been well operating currently.

CNC850 Vertical Machining Center Technical Parameters

1. Travel Distances

  • X-axis (table left/right): 800 mm
  • Y-axis (table front/back): 500 mm
  • Z-axis (spindle head up/down): 530 mm
  • Distance from spindle center to column guide: 550 mm
  • Distance from spindle nose to table: 126-656 mm

2. Specifications

  • Table size: 500 × 1050 mm
  • Number of T-slots: 5
  • T-slot width: 18 mm
  • Maximum table load: 600 kg
  • Spindle speed control: Stepless
  • Spindle speed range: 60~8000 rpm
  • Spindle taper: BT40-Ø150
    Standard Accessories: Optional Accessories:
    1. Resin sand castings (X/Y axis linear guideway, Z axis box way) 1. Disc-type tool magazine (Taiwan Kang 田)
    2. Ball screws and linear guideways (Taiwan Hiwin/PMI) 2. Umbrella-type tool magazine (Taiwan Kang 田)
    3. BT40 spindle with 8000 rpm (Taiwan 普森 / Luoyi/Danquan) 3. Spindle oil cooling (WHO)
    4. Tool striking cylinder (Taiwan Shangpin) 4. Chip conveyor
    5. Spindle timing pulley and timing belt (Taiwan) 5. Fourth axis (Taiwan Tanjia)
    6. Bearings (Japan NSK)
    7. X, Y, Z axis stainless steel 防护罩
    8. Japan Mitsubishi M80 system
    9. Three-axis Mitsubishi original servo motors
    10. Main electrical components (Germany Schneider)
    11. Machining air blowing device (Taiwan AIRTAC)
    12. Machining oil flushing device (Taiwan Zhangtie)
    13. Electric lubrication system (Sino-Japanese joint venture Hegu)
    14. Fully enclosed outer cover
    15. Electrical box heat exchanger (EA-05N)
    16. Adjusting pads + screws, tools, document box
    17. 1 piece of LED long-life work light
10012

Brazilian Miner Vale SA

23 large-scale ball mills, Ø5.5×8.8m
10013

Wengfu Phosphate Mine Project Phase II in Saudi Arabia (Ma'aden)

6 wet grinding rod mills, Ø4.6×6.7m
10014

Vedanta Project in South Africa

1 SAG mill, Ø8.5×5.5m
10010 (1)

Laos Phonesack Group's KSO Gold Mine Project (83,000t/d)

6 SAG mills, Ø8.8×4.8m
10011

Mongolian Erdenet Mining Corporation's Copper Mine Project (20,000t/d)

SAG mill, Ø9.75×4.88m
Full-process Solution for Mineral Grinding

We believe the projects that we have executed speak for themselves. CITIC HIC has engineered and provided 6 AG mills of Ø12.2m×11m (28000kW gearless drive) and 6 overflow discharge ball mills of Ø7.9×13.6m (2×9000kW gear drive) for Sino Iron Project in Australia. For Zijin Mining’s Duobaoshan Copper Mine project in Heilongjiang, we have manufactured and provided SAG mills of Ø11×6.4m (2×9000kW) and overflow discharge ball mills of Ø7.9×13.6m (2×9000kW) which have been well operating currently.

Why Choose CITIC HIC's Grinding Mills
  • High cost-effectiveness
    CITIC HIC grinding mills are recognized as China’s Manufacturing Industry Single Champion Product. CITIC HIC is responsible for setting the national standards of semi-autogenous mills (SAG mills) and ball mils, supported by powerful database, optimized process technology, cutting-edge design concept, and 60 years of experience in developing and nurturing innovative technology.
  • High operating rate
    The long life cycle of our products is based on the adoption of international standards, high-quality materials, state-of-the-art processing techniques.
  • Low-carbon & environmental-friendly processes
    Intelligent control technology coupled with long-life wear-resistant materials results in low-carbon and eco-friendly operations.
  • High-efficiency service
    Our service network is distributed all over the world, and our service team of seasoned professionals is reliable and willing to assist along the way. We are able to deliver quick response to customer needs and provide full life cycle support via online monitoring and diagnosing, product upgrading and continuous process improvement.
